Square D LAL26300 2-Pole 300A 600V Circuit Breaker L-Frame 300 Amp 2P Unit Mount
$800.00
Specifications
- Part Number
- LAL26300
- Amperage
- 300 Amp
- Manufacturer
- Square D
- Condition
- Used
- Interrupt Rating
- 22kA @ 600VAC; 30kA @ 480VAC; 42kA @ 240VAC
- Maximum Amperage
- 300A
- Poles
- 2
- Voltage
- 600 Volt
In Stock1 Used unit available
Description
Square D LAL26300 Molded Case Circuit Breaker
High Capacity: 300 Amp rating for heavy-duty commercial and industrial applications.
Advanced Protection: Features thermal-magnetic trip technology for both overload and short-circuit protection.
Amperage: 300A.
Voltage: 600VAC / 250VDC.
Poles: 2-Pole.
Interrupting Rating: 22kA @ 600VAC; 30kA @ 480VAC; 42kA @ 240VAC.
SKU: LAL26300-U
Weight: 20 lbs
Save with Used
Same part number, tested & ready to ship
1 available
